1 Pole 6A Schneider Miniature Circuit Breaker

Rs. 1,750.00

Negotiable

Store | VERIFIED

WEDABIMA HARDWARE Electrical Products

Call

0774953653

[email protected]

Location

Sausiri Complex , High Level Road , Nugegoda

BUY NOW

Description

1 Pole 6A Schneider Miniature Circuit Breaker

Brand - Schneider

Model - A9N1P06C

Range of Product - Distribution

Product or Component Type - Acti9

Range - Acti9

Product name - XC60

Product or Component Type - Miniature circuit-breaker

Device short Name - XC60

Poles Description - 1P

Number of Protected Poles - 1

[In] Rated Current - 6 A

Network Type - AC/DC

Trip Unit Technology - Thermal-magnetic

Curve Code - C

Utilisation Category - Category A conforming to EN/IEC 60947-2

Suitability for Isolation - Yes conforming to EN/IEC 60947-2

Complementary

Network frequency - 50/60 Hz
[Ue] rated operational voltage - 220...240 V AC 50/60 Hz 12...48 V DC
60 V DC
Magnetic tripping limit - 8 x In +/- 20 %

Breaking capacity - 10000 A Icn at 240 V AC 50/60 Hz conforming to EN/IEC 60898-1
10 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-2
15 kA Icu at 12...48 V DC conforming to EN/IEC 60947-2
6 kA Icu at 60 V DC conforming to EN/IEC 60947-2

[Ics] rated service breaking capacity - 15 kA conforming to EN/IEC 60947-2 - 12...48 V DC
6 kA conforming to EN/IEC 60947-2 - 60 V DC
Limitation class - 3 conforming to EN/IEC 60898-1
3 conforming to EN/IEC 60947-2

[Ui] rated insulation voltage - 500 V AC 50/60 Hz conforming to EN/IEC 60947-2

[Uimp] rated impulse withstand voltage - 6 kV conforming to EN/IEC 60947-2
Contact position indicator - Yes
Control type - Toggle

Local signalling - ON/OFF indication
mounting mode - Clip-on
mounting support - 35 mm DIN rail
Comb busbar and distribution block compatibility - Top: YES
9 mm pitches - 2
Height - 85 mm
Width - 18 mm
Depth - 77.5 mm
net weight - 0.115 kg
Colour - White

Mechanical durability - 20000 cycles
Electrical durability - 20000 cycles
Connections - terminals Tunnel type terminals (bottom) 16 mm² flexible
Tunnel type terminals (bottom) 25 mm² rigid
Biconnect (top)
Wire stripping length - 13 mm for top or bottom connection
Tightening torque - 2 N.m
Earth-leakage protection - Separate block
Product compatibility - C60 auxiliary
C60 accessories
Overvoltage category - IV

Environment
Standards EN/IEC 60947-2 EN/IEC 60898-1
Pollution degree - 3
Tropicalisation - 2 conforming to IEC 60068-1
Relative humidity - 95 % at 55 °C
ambient air temperature for operation - 30…70 °C
ambient air temperature for storage - 40…85 °C

Packing Units
Unit Type of Package 1 - PCE
Number of Units in Package 1 - 1
Package 1 - Height 2.6 cm
Package 1 - Width 8.4 cm
Package 1 - Length 8 cm
Package 1 - Weight 100 g

Unit Type of Package 2 - BB1
Number of Units in Package 2 - 12
Package 2 Height - 9.4 cm
Package 2 Width - 9.8 cm
Package 2 Length - 24.6 cm/ Package 2 - Weight 1.32 kg

Unit Type of Package 3 - S03
Number of Units in Package 3 - 144
Package 3 Height - 30 cm
Package 3 Width - 30 cm
Package 3 Length - 40 cm
Package 3 Weight - 16.58 kg
