2 Pole 63A Schneider Switch Disconnector

Rs. 4,520.00

Negotiable

Store | VERIFIED

WEDABIMA HARDWARE Electrical Products

Call

0774953653

[email protected]

Location

Sausiri Complex , High Level Road , Nugegoda

BUY NOW

Description

2 Pole 63A Schneider Switch Disconnector

Brand - Schneider

Model - EZ9S16263

Range - Easy9

Product or Component Type - Switch

Device short name - Easy9 switch

Switch Application - Distribution

Poles - 2P

Utilisation Category - AC-22A

Suitability for Isolation - Yes

Complementary
[Ie] rated operational current - 63 A at 400 V 50/60 Hz
[Ue] rated operational voltage - 400 V AC 50/60 Hz
[Icm] rated short-circuit making capacity - 0.945 kA
[Icw] rated short-time withstand current - 0.756 kA during 1 s
[Ui] rated insulation voltage - 500 V AC 50/60 Hz
[Uimp] rated impulse withstand voltage - 4 kV

Control type - Toggle
Local signalling - ON/OFF indication
Contact position indicator - Yes
mounting mode - Clip-on
mounting support - DIN rail
9 mm pitches - 4
Height - 81 mm
Width - 36 mm
Depth - 66.5 mm
Colour - Grey

Mechanical durability - 8500 cycles
Electrical durability - 1500 cycles
Connections - terminals Tunnel type terminal (top or bottom) 1…35 mm² rigid
Tunnel type terminal (top or bottom) 1…25 mm² flexible
Tightening torque - 3.5 N.m

Environment
Standards - IEC 60947-3
Product certifications - CE
IP degree of protection - IP20 conforming to IEC 60529
Tropicalisation - 2
ambient air temperature for operation - 5…55 °C
ambient air temperature for storage - 5…70 °C

Packing Units
Unit Type of Package 1 - PCE
Number of Units in Package 1 - 1
Package 1 Height - 7.81 cm
Package 1 Width - 3.6 cm
Package 1 Length - 8.52 cm
Package 1 Weight - 182.0 g

Unit Type of Package 2 - S03
Number of Units in Package 2 - 72
Package 2 Height - 30.0 cm
Package 2 Width - 30.0 cm
Package 2 Length - 40.0 cm
Package 2 Weight - 12.883 kg
